George Zhu

Recent Posts

The Importance of Optical Detectors

Posted by George Zhu on Tue, Jul 24, 2018 @ 18:07 PM
In the previous article, I briefly explained and compared two types of optical sources used in transmitters: LED and LD. Today, I am going to discuss what happens at the other end of a fiber link -- detectors. Optical detectors, as the name implied, can detect the amount of light received. Our very own eyes are a pair of detectors as they can receive light information with the retina and transmit that light data to our brain. In the visible light spectrum, our eyes are great detectors to inspect fiber break or light leakage. However, most fiber works in the invisible wavelength spectrum where human eyes won't be able to see. That is the where the optical detectors come in .
Read More

Topics: graded-index fiber,, optical detectors

Understanding Radiation Resistant Fiber: What you need to know

Posted by George Zhu on Thu, Jan 11, 2018 @ 16:01 PM

 Under the ideal environment condition, the primary fiber attenuation in single mode fiber comes from intrinsic characteristics of the glass and is usually less than 0.2 dB/km. However, when the fiber is exposed to high radiation environment for an extended period, for example in a nuclear facility, the fiber's Radiation-Induced Attenuation (RIA) will accumulate and become fiber's dominant source of loss as the electrons are trapped in the glass due to ionizing radiation. It also takes time for the fiber to recover from the radiation after the radiation source is removed. Depending on the temperature, radiation doses, and radiation sources, the fiber may or may not recover to its original state.

Read More

Topics: om4 fiber, om3 fiber, multimode fiber, corning clearcurve, step-index fiber,, graded-index fiber,

Multimode Graded Index Fiber: What It Is And Why You Need To Know

Posted by George Zhu on Wed, Jan 3, 2018 @ 11:01 AM

Graded-Index Fiber, also known as G.651.1 under International Telecommunication Union (ITU) standards, is a type of fiber whose refractive index decreases gradually as the radial distance (distance to the core center) increases. In comparison, what we commonly have seen is G.652.D fiber which has a step-index refractive index profile. This article will compare graded-index multimode fiber with traditional step-index fiber, as well as its advantages when dealing with modal dispersion, a common signal distortion error.

The graph below shows the different refractive index profiles of the fiber core and cladding.

Read More

Topics: om4 fiber, om3 fiber, multimode fiber, corning clearcurve, step-index fiber,, graded-index fiber,

An Introduction to Large Core Optical Fibers

Posted by George Zhu on Thu, Sep 28, 2017 @ 10:09 AM

The most common multimode optical fibers, which allow multiple light modes to propogate along the link simultaneously, are designed with a core diameter size of 50µm for for high-speed communications networks.  You may recognize these types of fibers by industry specifications such as OM2, OM3, and OM4 or by brand names like Corning® ClearCurve® and OFS® LaserWave®.

Read More

Topics: optical fibers, specialty optical fibers, medical fibers, high power lasers, large core fibers, multimode optical fibers

How Does a Dispersion Compensating Fiber Reduce Chromatic Dispersion?

Posted by George Zhu on Thu, Apr 27, 2017 @ 16:04 PM

An important factor in the performance of fiber optic communications systems, chromatic dispersion is a topic and performance characteristic that is important to both understand and account for when operating and/or designing equipment for fiber-based networks.

Read More

Topics: optical fiber, refractive index, chromatic dispersion, dispersion compensating fiber, dispersion compensating module
